High-Thrust Jet Fan for Car Park & Basement Ventilation
Limited stock available! Order soon.
Our Axial Jet Fans, also known as impulse fans or turbo jet fans, are the core component of a modern jet fan ventilation system. Engineered for high performance in basement car park ventilation and tunnels, these jet fans ensure superior air quality, effective smoke management, and significant energy savings by eliminating the need for costly ductwork.
Preliminary Jet Fan Estimator
Estimated Fans Required: ---
Disclaimer: This is a preliminary estimate for budgeting only. Contact us for a detailed CFD analysis.
How Does a Jet Fan Work?
The Principle of Induction
A jet fan working principle is based on moving a large volume of air via induction. The air jet fan creates a high-velocity stream of air. This jet stream mixes with the surrounding stationary air, imparting momentum to it and causing a large volume of air (typically 10-12 times the fan's primary airflow) to move in a specific direction.
This process allows a series of small jet fans to control air movement across a large area, like an underground car park, without a ducted car park ventilation system. The jet fan purpose is to direct pollutants like CO towards the main jet exhaust fan locations.
Advantages of a Jet Fan Ventilation System
Space-Saving Design
Eliminates the need for bulky ductwork, maximizing overhead clearance in basement car parks and reducing installation complexity and cost.
Enhanced Safety & Air Quality
Ensures effective dilution and removal of CO and pollutants. The car park smoke ventilation system mode controls smoke flow in case of a fire, clearing escape routes.
Energy Efficient
Operates only when needed, controlled by CO sensors. The high efficiency jet fan motor and targeted ventilation reduce overall energy consumption compared to traditional systems.
Jet Fan Uses & Key Applications
Basement Car Park Ventilation
The primary jet fan use. Ideal for jet fans for car park ventilation, ensuring compliance with car park ventilation standards.
Tunnel Ventilation
Used as a jet fan in tunnel applications for maintaining air quality and for emergency smoke extraction.
Industrial Spaces
Provides effective general ventilation and spot cooling/extraction in large workshops and factories.
Bus Depots & Service Bays
This jet exhaust fan is perfect for removing harmful diesel fumes in large vehicle service areas.
Jet Fan Specification
Our jet fan specification can be customized to meet your precise project needs. Below are the standard options available in our jet fan catalogue.
| Parameter | Value |
|---|---|
| Fan Type | Unidirectional or Fully Reversible Axial Jet Fan |
| Diameter Range (Jet Fan Size) | 315mm - 630mm |
| Thrust (Jet Fan Thrust) | 15N to 100N |
| Jet Fan Motor | TEFC, Class H insulation, IP55 protection. Standard 2 speed jet fan or VFD-compatible motor. |
| Airflow Capacity (Jet Fan CFM) | Up to 12,000 CMH (Approx. 7,000 CFM) |
| Jet Fan Blade Material | Aerofoil section, die-cast Aluminium Alloy, balanced for low vibration. |
| Casing & Silencers | Heavy gauge galvanized steel with integrated, high-attenuation silencers to reduce jet fan noise. |
| High-Temp Rating | Available for smoke ventilation (e.g., 250°C / 2 hrs) as per EN 12101-3. |
| Jet Fan Dimensions | Available on technical data sheet or jet fan catalogue pdf. |
Jet Fan Ventilation System Design & Installation
Car Park Ventilation Design & Calculation
A successful jet fan system relies on expert design. Our engineering team assists with the complete car park ventilation system design, including CFD analysis to ensure optimal fan placement and performance. We perform car park ventilation calculation based on car park ventilation standards ASHRAE, local building codes, and your specific car park ventilation requirements.
Key considerations for a jet fan design include the garage geometry, required air change rates (ACH), CO monitoring, and smoke control strategy. We can provide a detailed car park ventilation calculation excel sheet for your project review.
Jet Fan Installation & Control
Proper jet fan installation is crucial. Our jet fan installation details guide covers mounting, spacing, and electrical connections. The system integrates with a central jet fan control panel that monitors CO levels and activates fans accordingly. We provide a complete jet fan control wiring diagram for seamless integration by your electrical contractor.
Supplying Jet Fans Across India
From our manufacturing base in Ahmedabad, we have a robust supply network to deliver our high-performance jet fan systems across the country. We are proud to be a leading supplier of jet fans in Ahmedabad, Vadodara, and Surat, with a strong presence in major metropolitan hubs.
We provide full project support and delivery of our jet fans in Mumbai, Delhi, Pune, Bangalore, Kolkata, Chennai, and Hyderabad. Whether your project is in the north, south, east, or west, our team is ready to assist with design, selection, and nationwide supply.
Frequently Asked Questions
Basement car park ventilation requirements are dictated by local building codes and standards like ASHRAE. They typically specify a minimum number of air changes per hour (ACH) for general ventilation (e.g., 6-10 ACH) to control CO levels, and a higher rate for emergency car park smoke ventilation. A jet fan system is an approved method to meet these requirements.
A jet fan calculation involves determining the total required thrust to overcome pressure losses and move air effectively through the car park. This jet fan thrust calculation considers the area's size, geometry, and any obstructions. For complex projects, Computational Fluid Dynamics (CFD) analysis is the most reliable method. Our team provides full car park ventilation calculation support.
Yes. As leading jet fan manufacturers in India, we have a robust supply chain to deliver our jet fan ventilation systems to all major metropolitan areas. We are a primary source for jet fans in Mumbai, Pune, Delhi, Bangalore, Kolkata, Chennai, and Hyderabad, in addition to our local Gujarat market of Ahmedabad, Surat, and Vadodara. Contact us for project consultations in your city.
Yes, we provide technical resources for consultants and designers. A jet fan CAD block and jet fan DWG file are available upon request to assist with integration into your car park ventilation design plans. Please contact our technical sales team.
